The MVS Connection

Wohlhaupter® GmbH developed the world's first modular tooling system called MultiBore in 1973. The modular tooling system was designed to be compatible with all machine spindles, and its connection features a triple point clamp (figure 1). The triple point clamp maximizes rigidity, and creates an accuracy less than 3µm when the tool is changed.

• Ensures high axial clamping forces on mating surfaces
• Provides maximum rigidity
• Threaded taper pins for precise cutter positioning

MVS Color Guide

Wohlhaupter® created a unique color-coding system to find the right connections for different tool components quickly and easily. Each Wohlhaupter / MVS connection size has its own color-coding. Simply match the colors to select the correct combination of tool components (figure 2).
